RM-2 Mk2

2-channel analog audio DJ mixer with a unique layout

  • 4-way eq isolators on each channel

  • Handcrafted custom brass knobs

  • Detachable flexible lamp

  • External handcrafted power supply

  • Stainless steel / aged brass enclosure

  • Hand-matched, populated, and soldered components (even SMD parts)

Tech specs

Inputs

  • 2 line stereo RCA

  • 2 phono stereo RCA

Outputs

  • Stereo Master balanced XLR (with level control fader)

  • Stereo Master unbalanced RCA (with level control fader)

  • Stereo Booth impedance balanced TRS 1/4" jacks (with

    level control fader)

  • Stereo Record unbalanced RCA (-6 dB fixed gain)

  • Stereo Headphones unbalanced TRS 1/4" jack

EQ Isolators

  • 4-band isolators on each channel

  • 2 pole (12dB per octave) full cut/+9dB boost response

  • crossover frequency

    • low / mid low - 200 Hz

    • mid low / mid high - 1 kHz

    • mid high / high - 5 kHz

Send / Return loop

  • Stereo Send (post-fader) output TRS 1/4" jack

  • Stereo Return input TRS 1/4" jack

  • Separate Send faders for each channel, common Return fader

Separate Cue faders for each channel

Stereo VU meters on Master output

Audio performance

Rev.2

Measured with QA403 Audio Analyzer

  • Phono stage RIAA error (20Hz to 20kHz): +/- 0.1 dB

  • Frequency response (20Hz to 20kHz): +/-1 dB

Phono input to master output (10mVRMS, 1kHz, through EQ isolator)

  • Total harmonic distortion < 0.003 %

  • Signal-to-noise ratio > 70 dB

Line input to master output (2VRMS, 1kHz, through EQ isolator)

  • Total harmonic distortion < 0.0003 %

  • Signal-to-noise ratio > 95 dB

What’s included

  • Khramov RM-2 Mk2 mixer

  • Khramov linear power supply

  • Power cord with plug for your country

  • Flexible LED lamp (made by Littlite in the USA)

  • Watertight, crushproof and dustproof travel case (made by Pelican in the USA)
